PRODUCT

產品介紹

Compact, lightweight and versatile.
5 selectable drag positions (pan and tilt) + 0.
16 selectable counterbalance positions, with CB Plus for precise counterbalance.
Perfect for payloads to 0 – 14.0 kg (0 – 30.9 lbs).
Fluid drag system with smooth start and soft stop technology & balanced diagonal transition.
Slim inline radial ring controls.
Illuminated bubble level.
Removable ball level stud for flat base mounting (sliders) with 3/8” screw hole.
Precise floating pan-tilt caliper locks ensure bounce free on-off performance.
Side loading camera plate with 60mm travel.
Robust construction for rugged outdoor shooting conditions.
Optional second pan handle mount.
2 side mounts for accessory blocks.
3 year warranty.

承重範圍 / Payload Range	0-14.0 kg (0-30.9 lbs)
重量 / Weight	2.5kg (5.5lbs)
動態平衡 / Counterbalance Positions	16 段 (15+0)
水平/垂直阻尼段數 / Pan Tilt Drag	5 段 + 0
水平阻尼固定 / Pan Tilt Locks	Positive lock calliper brake system
垂直頃斜範圍 / Tilt Range	+ 90°/ -75°
水平旋轉範圍 / Pan Range	360°
攝影機底版 / Camera Platform	Quick release, side load camera plate
底版調整範圍 / Sliding Range	60mm (2.4″)
雲台碗座 / Mounting Base	Ø100mm (3.9″) ball levelling with 3 x M5 holes for flat base mounting
碗座以上高度 / Height Above Bowl	150mm (6.0″)
照明功能 / Illuminated Controls	Bubble level, pan-tilt drag controls
手柄（Pan 桿） / Pan Handle	Fixed length 390mm (15.4″)
使用溫度 / Temperature Range	-40° to +65°C (-40° to +149°F)
