PRODUCT

產品介紹

Fluid drag system with smooth start and soft stop technology & balanced diagonal transitions.
16 positions of counterbalance.
Payload range from 2kg (4.4lbs) up to 21kg (46.2lbs).
Pan and tilt drag 7+0 positions.
Side loading camera platform, with safety lock, to suite Arri/OConnor or compatible camera plates.
150mm camera plate sliding range.
Multiple mounting bases: CiNX is adaptable to a Mitchel base plate, 100mm or 150mm ball levelling (supplied with 100mm ball levelling).
4 Arri type accessory mounting points.
Illuminated bubble level and pan-tilt drag controls.
Precise floating pan-tilt calliper locks ensure bounce free on-off performance.
Removable ball level stud allows for flat base mounting with 3/8” screw thread.
Optional second pan handle mount.
3 years warranty.

承重範圍 / Payload Range	2-21kg (4.4-46.2lbs)
重量 / Weight	4.0kg (8.8lbs)
動態平衡 / Counterbalance Positions	16 段 (15+0)
水平/垂直阻尼段數 / Pan Tilt Drag	7 段 + 0
水平阻尼固定 / Pan Tilt Locks	Positive lock calliper brake system
垂直頃斜範圍 / Tilt Range	+ 90°/ -75°
水平旋轉範圍 / Pan Range	360°
攝影機底版 / Camera Platform	Side load quick release camera plage (Arri type)
底版調整範圍 / Sliding Range	150mm (5.9”)
雲台碗座 / Mounting Base	Ø100mm (3.9″) ball levelling (std.) Ø150mm (5.9″) ball levelling (opt.) Mitchell Base (opt.)
碗座以上高度 / Height Above Bowl	202mm (8.0”)
照明功能 / Illuminated Controls	Bubble level, pan-tilt drag controls
手柄（Pan 桿） / Pan Handle	Telescopic 390 to 590mm (15.4 to 23.2”)
使用溫度 / Temperature Range	-40° to +65°C (-40° to +149°F)
